R88減速機傳動比計算：齒輪減速馬達

輸送帶參數：輪子直徑180，負載4噸，一分鐘走15米

15米÷（0.18輪子直徑×3.14）=26.53轉每分鐘

4噸換算成N=40000N

40000×0.09輪子半徑×0.06摩擦系數=216N.m

通常確保萬無一失，我們會把輸出扭矩放大兩倍216×2=432N.m

電機轉數1400÷輸出轉數26.53=52.77比

432N.m輸出扭矩÷52.77比=8.19N.m電機扭矩

8.19N.m電機扭矩換算成功率1.299KW以上

對應的R88減速機選型參數：

型號：R89-B1.5KW

減速比：52.82

輸出轉數：27轉每分鐘

輸出扭矩：525N.m

安全系數：2.90

R88減速機平面圖紙：輸出軸Φ20+鍵2.5（可定做），高134*寬135*長174（帶輸出軸）R系列減速機

R88臥式硬齒面斜齒輪減速機型號：

R87FDM100L4,R87FDM100LC4,R87FDM100LS4,R87FDM100M4,R87FDM112M4,R87FDM132L4,R87FDM132M4,R87FDM132MC4,R87FDM132ML4,R87FDM132S4,R87FDM160L4,R87FDM160M4,R87FDM160MC4,R87FDM160S4,R87FDM180L4,R87FDM180LC4,R87FDM180M4,R87FDM180S4,R87FDM200L4,R87FDM71D4,R87FDM71M4,R87FDM71MS4,R87FDM71S4,R87FDM80K4,R87FDM80M4,R87FDM80MK4,R87FDM80N4,R87FDM80S4,R87FDM90L4,R87FDM90M4,R87FDM90S4,R87FDR100L4,R87FDR100LC4,R87FDR100LS4,R87FDR100M4,R87FDR112M4,R87FDR132L4,R87FDR132M4,R87FDR132MC4,R87FDR132ML4,R87FDR132S4,R87FDR160L4,R87FDR160M4,R87FDR160MC4,R87FDR160S4,R87FDR180L4,R87FDR180LC4,R87FDR180M4,R87FDR180S4,R87FDR200L4,R87FDR71D4,R87FDR71M4,R87FDR71MS4,R87FDR71S4,R87FDR80K4,R87FDR80M4,R87FDR80MK4,R87FDR80N4,R87FDR80S4,R87FDR90L4,R87FDR90M4,R87FDR90S4,R87FDRE100L4,R87FDRE100LC4,R87FDRE100LS4,R87FDRE100M4,R87FDRE112M4,R87FDRE132L4,R87FDRE132M4,R87FDRE132MC4,R87FDRE132ML4,R87FDRE132S4,R87FDRE160L4,R87FDRE160M4,R87FDRE160MC4,R87FDRE160S4,R87FDRE180L4,R87FDRE180LC4,R87FDRE180M4,R87FDRE180S4,R87FDRE200L4,R87FDRE71D4,R87FDRE71M4,R87FDRE71MS4,R87FDRE71S4,R87FDRE80K4,R87FDRE80M4,R87FDRE80MK4,R87FDRE80N4,R87FDRE80S4,R87FDRE90L4,R87FDRE90M4,R87FDRE90S4,R87FDRN100L4,R87FDRN100LC4,R87FDRN100LS4,R87FDRN100M4,R87FDRN112M4,R87FDRN132L4,R87FDRN132M4,R87FDRN132MC4,R87FDRN132ML4,R87FDRN132S4,R87FDRN160L4,R87FDRN160M4,R87FDRN160MC4,R87FDRN160S4,R87FDRN180L4,R87FDRN180LC4,R87FDRN180M4,R87FDRN180S4,R87FDRN200L4,R87FDRN71D4,R87FDRN71M4,R87FDRN71MS4,R87FDRN71S4,R87FDRN80K4,R87FDRN80M4,R87FDRN80MK4,R87FDRN80N4,R87FDRN80S4,R87FDRN90L4,R87FDRN90M4,R87FDRN90S4,R87FDRS100L4,R87FDRS100LC4,R87FDRS100LS4,R87FDRS100M4,R87FDRS112M4,R87FDRS132L4,R87FDRS132M4,R87FDRS132MC4,R87FDRS132ML4,R87FDRS132S4,R87FDRS160L4,R87FDRS160M4,R87FDRS160MC4,R87FDRS160S4,R87FDRS180L4,R87FDRS180LC4,R87FDRS180M4,R87FDRS180S4,R87FDRS200L4,R87FDRS71D4,R87FDRS71M4,R87FDRS71MS4,R87FDRS71S4,R87FDRS80K4,R87FDRS80M4,R87FDRS80MK4,R87FDRS80N4,R87FDRS80S4,R87FDRS90L4,R87FDRS90M4,R87FDRS90S4,R87FDT100L4,R87FDT100LC4,R87FDT100LS4,R87FDT100M4,R87FDT112M4,R87FDT132L4,R87FDT132M4,R87FDT132MC4,R87FDT132ML4,R87FDT132S4,R87FDT160L4,R87FDT160M4,R87FDT160MC4,R87FDT160S4,R87FDT180L4,R87FDT180LC4,R87FDT180M4,R87FDT180S4,R87FDT200L4,R87FDT71D4,R87FDT71M4,R87FDT71MS4,R87FDT71S4,R87FDT80K4,R87FDT80M4,R87FDT80MK4,R87FDT80N4,R87FDT80S4,R87FDT90L4,R87FDT90M4,R87FDT90S4,R87FDV100L4,R87FDV100LC4,R87FDV100LS4,R87FDV100M4,R87FDV112M4,R87FDV132L4,R87FDV132M4,R87FDV132MC4,R87FDV132ML4,R87FDV132S4,R87FDV160L4,R87FDV160M4,R87FDV160MC4,R87FDV160S4,R87FDV180L4,R87FDV180LC4,R87FDV180M4,R87FDV180S4,R87FDV200L4,R87FDV71D4,R87FDV71M4,R87FDV71MS4,R87FDV71S4,R87FDV80K4,R87FDV80M4,R87FDV80MK4,R87FDV80N4,R87FDV80S4,R87FDV90L4,R87FDV90M4,R87FDV90S4,R87FDVE100L4,R87FDVE100LC4,R87FDVE100LS4,R87FDVE100M4,R87FDVE112M4,R87FDVE132L4,R87FDVE132M4,R87FDVE132MC4,R87FDVE132ML4,R87FDVE132S4,R87FDVE160L4,R87FDVE160M4,R87FDVE160MC4,R87FDVE160S4,R87FDVE180L4,R87FDVE180LC4,R87FDVE180M4,R87FDVE180S4,R87FDVE200L4,R87FDVE71D4,R87FDVE71M4,R87FDVE71MS4,R87FDVE71S4,R87FDVE80K4,R87FDVE80M4,R87FDVE80MK4,R87FDVE80N4,R87FDVE80S4,R87FDVE90L4,R87FDVE90M4,R87FDVE90S4,R87F-Y0.37KW,R87F-Y0.55KW,R87F-Y0.75KW,R87F-Y1.1KW,R87F-Y1.5KW,R87F-Y100M4,R87F-Y112M4,R87F-Y11KW,R87F-Y132M4,R87F-Y15KW,R87F-Y160M4,R87F-Y18.5KW,R87F-Y180M4,R87F-Y2.2KW,R87F-Y200M4,R87F-Y22KW,R87F-Y30KW,R87F-Y3KW,R87F-Y4KW,R87F-Y5.5KW,R87F-Y7.5KW,R87F-Y71M4,R87F-Y80M4,R87F-Y90M4,R87F-YEJ0.37KW,R87F-YEJ0.55KW,R87F-YEJ0.75KW,R87F-YEJ1.1KW,R87F-YEJ1.5KW,R87F-YEJ100M4,R87F-YEJ112M4,R87F-YEJ11KW,R87F-YEJ132M4,R87F-YEJ15KW,R87F-YEJ160M4,R87F-YEJ18.5KW,R87F-YEJ180M4,R87F-YEJ2.2KW,R87F-YEJ200M4,R87F-YEJ22KW,R87F-YEJ30KW,R87F-YEJ3KW,R87F-YEJ4KW,R87F-YEJ5.5KW,R87F-YEJ7.5KW,R87F-YEJ71M4,R87F-YEJ80M4,R87F-YEJ90M4,R87F-YVP0.37KW,R87F-YVP0.55KW,R87F-YVP0.75KW,R87F-YVP1.1KW,R87F-YVP1.5KW,R87F-YVP100M4,R87F-YVP112M4,R87F-YVP11KW,R87F-YVP132M4,R87F-YVP15KW,R87F-YVP160M4,R87F-YVP18.5KW,R87F-YVP180M4,R87F-YVP2.2KW,R87F-YVP200M4,R87F-YVP22KW,R87F-YVP30KW,R87F-YVP3KW,R87F-YVP4KW,R87F-YVP5.5KW,R87F-YVP7.5KW,R87F-YVP71M4,R87F-YVP80M4,R87F-YVP90M4,R87F-YVPEJ0.37KW,R87F-YVPEJ0.55KW,R87F-YVPEJ0.75KW,R87F-YVPEJ1.1KW,R87F-YVPEJ1.5KW,R87F-YVPEJ100M4,R87F-YVPEJ112M4,R87F-YVPEJ11KW,R87F-YVPEJ132M4,R87F-YVPEJ15KW,R87F-YVPEJ160M4,R87F-YVPEJ18.5KW,R87F-YVPEJ180M4,R87F-YVPEJ2.2KW,R87F-YVPEJ200M4,R87F-YVPEJ22KW,R87F-YVPEJ30KW,R87F-YVPEJ3KW,R87F-YVPEJ4KW,R87F-YVPEJ5.5KW,R87F-YVPEJ7.5KW,R87F-YVPEJ71M4,R87F-YVPEJ80M4,R87F-YVPEJ90M4。

R88系列減速機參數大全：同軸斜齒輪減速電機

R88減速機配0.37KW電機參數

R88減速機配0.55KW電機參數

R88減速機配0.75KW電機參數

R88減速機配1.1KW電機參數

R88減速機配1.5KW電機參數

R88減速機配2.2KW電機參數

R88減速機配3KW電機參數

R88減速機配4KW電機參數

R88減速機配5.5KW電機參數

R88減速機配7.5KW電機參數

R88減速機配11KW電機參數

R88減速機配15KW電機參數

R88減速機配18.5KW電機參數

R88減速機配22KW電機參數

R88減速機生產工廠展示：看廠請聯系微信13827261050，獲取位置，需提前一天預約

推薦類似型號：R78減速機
