R48減速機傳動比計算：齒輪減速馬達

輸送帶參數：輪子直徑100，負載2噸，一分鐘走35米

35米÷（0.1輪子直徑×3.14）=111.46轉每分鐘

2噸換算成N=20000N

20000×0.05輪子半徑×0.06摩擦系數=60N.m

通常確保萬無一失，我們會把輸出扭矩放大兩倍60×2=120N.m

電機轉數1400÷輸出轉數111.46=12.56比

120N.m輸出扭矩÷12.56比=9.55N.m電機扭矩

9.55N.m電機扭矩?fù)Q算成功率1.5KW以上

對應的R48減速機選型參數：

型號：R48-B1.5KW

減速比：12.54

輸出轉數：114轉每分鐘

輸出扭矩：126N.m

安全系數：2.0

R48減速機平面圖紙：輸出軸Φ20+鍵2.5（可定做），高134*寬135*長174（帶輸出軸）R系列減速機

R48臥式硬齒面斜齒輪減速機型號：

R47FDM100L4,R47FDM100LC4,R47FDM100LS4,R47FDM100M4,R47FDM112M4,R47FDM132L4,R47FDM132M4,R47FDM132MC4,R47FDM132ML4,R47FDM132S4,R47FDM63L4,R47FDM63M4,R47FDM63MS4,R47FDM63S4,R47FDM71D4,R47FDM71M4,R47FDM71MS4,R47FDM71S4,R47FDM80K4,R47FDM80M4,R47FDM80MK4,R47FDM80N4,R47FDM80S4,R47FDM90L4,R47FDM90M4,R47FDM90S4,R47FDR100L4,R47FDR100LC4,R47FDR100LS4,R47FDR100M4,R47FDR112M4,R47FDR132L4,R47FDR132M4,R47FDR132MC4,R47FDR132ML4,R47FDR132S4,R47FDR63L4,R47FDR63M4,R47FDR63MS4,R47FDR63S4,R47FDR71D4,R47FDR71M4,R47FDR71MS4,R47FDR71S4,R47FDR80K4,R47FDR80M4,R47FDR80MK4,R47FDR80N4,R47FDR80S4,R47FDR90L4,R47FDR90M4,R47FDR90S4,R47FDRE100L4,R47FDRE100LC4,R47FDRE100LS4,R47FDRE100M4,R47FDRE112M4,R47FDRE132L4,R47FDRE132M4,R47FDRE132MC4,R47FDRE132ML4,R47FDRE132S4,R47FDRE63L4,R47FDRE63M4,R47FDRE63MS4,R47FDRE63S4,R47FDRE71D4,R47FDRE71M4,R47FDRE71MS4,R47FDRE71S4,R47FDRE80K4,R47FDRE80M4,R47FDRE80MK4,R47FDRE80N4,R47FDRE80S4,R47FDRE90L4,R47FDRE90M4,R47FDRE90S4,R47FDRN100L4,R47FDRN100LC4,R47FDRN100LS4,R47FDRN100M4,R47FDRN112M4,R47FDRN132L4,R47FDRN132M4,R47FDRN132MC4,R47FDRN132ML4,R47FDRN132S4,R47FDRN63L4,R47FDRN63M4,R47FDRN63MS4,R47FDRN63S4,R47FDRN71D4,R47FDRN71M4,R47FDRN71MS4,R47FDRN71S4,R47FDRN80K4,R47FDRN80M4,R47FDRN80MK4,R47FDRN80N4,R47FDRN80S4,R47FDRN90L4,R47FDRN90M4,R47FDRN90S4,R47FDRS100L4,R47FDRS100LC4,R47FDRS100LS4,R47FDRS100M4,R47FDRS112M4,R47FDRS132L4,R47FDRS132M4,R47FDRS132MC4,R47FDRS132ML4,R47FDRS132S4,R47FDRS63L4,R47FDRS63M4,R47FDRS63MS4,R47FDRS63S4,R47FDRS71D4,R47FDRS71M4,R47FDRS71MS4,R47FDRS71S4,R47FDRS80K4,R47FDRS80M4,R47FDRS80MK4,R47FDRS80N4,R47FDRS80S4,R47FDRS90L4,R47FDRS90M4,R47FDRS90S4,R47FDT100L4,R47FDT100LC4,R47FDT100LS4,R47FDT100M4,R47FDT112M4,R47FDT132L4,R47FDT132M4,R47FDT132MC4,R47FDT132ML4,R47FDT132S4,R47FDT63L4,R47FDT63M4,R47FDT63MS4,R47FDT63S4,R47FDT71D4,R47FDT71M4,R47FDT71MS4,R47FDT71S4,R47FDT80K4,R47FDT80M4,R47FDT80MK4,R47FDT80N4,R47FDT80S4,R47FDT90L4,R47FDT90M4,R47FDT90S4,R47FDV100L4,R47FDV100LC4,R47FDV100LS4,R47FDV100M4,R47FDV112M4,R47FDV132L4,R47FDV132M4,R47FDV132MC4,R47FDV132ML4,R47FDV132S4,R47FDV63L4,R47FDV63M4,R47FDV63MS4,R47FDV63S4,R47FDV71D4,R47FDV71M4,R47FDV71MS4,R47FDV71S4,R47FDV80K4,R47FDV80M4,R47FDV80MK4,R47FDV80N4,R47FDV80S4,R47FDV90L4,R47FDV90M4,R47FDV90S4,R47FDVE100L4,R47FDVE100LC4,R47FDVE100LS4,R47FDVE100M4,R47FDVE112M4,R47FDVE132L4,R47FDVE132M4,R47FDVE132MC4,R47FDVE132ML4,R47FDVE132S4,R47FDVE63L4,R47FDVE63M4,R47FDVE63MS4,R47FDVE63S4,R47FDVE71D4,R47FDVE71M4,R47FDVE71MS4,R47FDVE71S4,R47FDVE80K4,R47FDVE80M4,R47FDVE80MK4,R47FDVE80N4,R47FDVE80S4,R47FDVE90L4,R47FDVE90M4,R47FDVE90S4,R47F-Y0.12KW,R47F-Y0.18KW,R47F-Y0.25KW,R47F-Y0.37KW,R47F-Y0.55KW,R47F-Y0.75KW,R47F-Y1.1KW,R47F-Y1.5KW,R47F-Y100M4,R47F-Y112M4,R47F-Y132M4,R47F-Y2.2KW,R47F-Y3KW,R47F-Y4KW,R47F-Y5.5KW,R47F-Y63M4,R47F-Y7.5KW,R47F-Y71M4,R47F-Y80M4,R47F-Y90M4,R47F-YEJ0.12KW,R47F-YEJ0.18KW,R47F-YEJ0.25KW,R47F-YEJ0.37KW,R47F-YEJ0.55KW,R47F-YEJ0.75KW,R47F-YEJ1.1KW,R47F-YEJ1.5KW,R47F-YEJ100M4,R47F-YEJ112M4,R47F-YEJ132M4,R47F-YEJ2.2KW,R47F-YEJ3KW,R47F-YEJ4KW,R47F-YEJ5.5KW,R47F-YEJ63M4,R47F-YEJ7.5KW,R47F-YEJ71M4,R47F-YEJ80M4,R47F-YEJ90M4,R47F-YVP0.12KW,R47F-YVP0.18KW,R47F-YVP0.25KW,R47F-YVP0.37KW,R47F-YVP0.55KW,R47F-YVP0.75KW,R47F-YVP1.1KW,R47F-YVP1.5KW,R47F-YVP100M4,R47F-YVP112M4,R47F-YVP132M4,R47F-YVP2.2KW,R47F-YVP3KW,R47F-YVP4KW,R47F-YVP5.5KW,R47F-YVP63M4,R47F-YVP7.5KW,R47F-YVP71M4,R47F-YVP80M4,R47F-YVP90M4,R47F-YVPEJ0.12KW,R47F-YVPEJ0.18KW,R47F-YVPEJ0.25KW,R47F-YVPEJ0.37KW,R47F-YVPEJ0.55KW,R47F-YVPEJ0.75KW,R47F-YVPEJ1.1KW,R47F-YVPEJ1.5KW,R47F-YVPEJ100M4,R47F-YVPEJ112M4,R47F-YVPEJ132M4,R47F-YVPEJ2.2KW,R47F-YVPEJ3KW,R47F-YVPEJ4KW,R47F-YVPEJ5.5KW,R47F-YVPEJ63M4,R47F-YVPEJ7.5KW,R47F-YVPEJ71M4,R47F-YVPEJ80M4,R47F-YVPEJ90M4。

R47系列減速機參數大全：同軸斜齒輪減速電機

R47F減速機配0.12KW電機參數

R47F減速機配0.18KW電機參數

R47F減速機配0.25KW電機參數

R47F減速機配0.37KW電機參數

R47F減速機配0.55KW電機參數

R47F減速機配0.75KW電機參數

R47F減速機配1.1KW電機參數

R47F減速機配1.5KW電機參數

R47F減速機配2.2KW電機參數

R47F減速機配3KW電機參數

R47F減速機配4KW電機參數

R47F減速機配5.5KW電機參數

R48減速機生產工廠展示：看廠請聯系微信13827261050，獲取位置，需提前一天預約

推薦類似型號：R38減速機
